Haltian IoT Gateway N8
Compact industrial IoT gateway with BLE 5.0 (Wirepas) and LTE/Ethernet connectivity
Overview
The Haltian IoT Gateway N8 (SolidSense N8) is a compact industrial IoT gateway that bridges Wirepas mesh sensor networks to cloud backends via LTE or Ethernet connectivity. Built on the NXP i.MX 8M Nano processor, it provides robust data routing for industrial and commercial IoT deployments.
The gateway supports BLE 5.0 with Wirepas Mesh protocol, enabling reliable communication with hundreds of wireless sensors. Multiple backhaul options (LTE Cat 4, Ethernet, WiFi) ensure continuous connectivity even in challenging network environments.
Key Features
- Wirepas Mesh Support: BLE 5.0 (nRF52833 SDR) for mesh network coordination
- Multiple Backhaul Options: LTE Cat 4, Gigabit Ethernet, WiFi 802.11ac
- Industrial Grade: 0-50°C operating temperature, 9-36V DC input
- Flexible Power: PoE support (BLE version) or DC power (9-36V)
- Compact Design: 150 x 85 x 40mm with DIN rail or wall mounting
- Programmable Status LEDs: Visual indication of system state
- Data Integrity: Supercap protection for data during power events
- Expandable: MicroSD card slot and internal expansion header
Quick Start
- Install and mount - Physical setup, power connection, and network configuration
- Configure connectivity - Set up Ethernet, WiFi, or LTE backhaul
- Deploy mesh network - Position gateway for optimal sensor coverage
- Monitor performance - Check network status and connectivity
Versions
The Gateway N8 is available in two versions:
| Version | Connectivity | Power | Use Case |
|---|---|---|---|
| BLE | Ethernet, WiFi, BLE | PoE or DC | Wired network deployments |
| LTE | LTE Cat 4, Ethernet, WiFi, BLE, CAN | DC only | Cellular deployments, vehicle installations |
Version Dependent Features
- LTE antenna and SIM card holder: LTE version only
- CAN interface: LTE version only
- PoE support: BLE version only
Device Identifiers
Haltian IoT
- Device Model: TBD (reverse URL notation)
- Serial Number: Printed on device label
Product Codes
- Model: N8 (SolidSense N8)
- Variants: N8-BLE (PoE), N8-LTE (Cellular)
Documentation Structure
- Installation - Mounting, power connection, network setup
- Configuration - Ethernet, WiFi, LTE, and Wirepas settings
- Operation - Network management, firmware updates, monitoring
- Specifications - Complete technical specifications
- Troubleshooting - Common issues and solutions
Support
For technical assistance:
- Email: support@haltian.com
- Review How-To Guides for setup procedures
